Cable Machine Buying Guide: Types, Space, Stack, Price
How to choose a cable machine: the four types, stack weight, pulley ratio, floor space and ceiling height, plus current prices and what delivery and assembly involve.
This cable machine buying guide comes down to three checks: your ceiling, your floor and the heaviest exercise you plan to do. Get those right, and the type mostly picks itself.
A cable machine is a steel frame with pulleys and a cable that links a handle to a weight stack or weight plates. Crossovers, pulley machines and functional trainers are all in the same family. You can browse them in our cable machines collection.
For most home gyms with an 8-foot ceiling, a compact functional trainer is the easiest fit. The Body-Solid Powerline PFT50 is 61 inches wide, 55 inches deep and 84 inches tall, with a 210 lb stack.
A full crossover needs a little over 9 feet of width.
Key takeaways
- Measure your ceiling first. Not every cable machine fits under 8 feet.
- Size the stack for your heaviest pull, such as a lat pulldown. Multiply the weight you want at the handle by the machine's pulley ratio (explained below) to get the stack you need.
- Most of our cable machines ship by LTL freight. Assembly takes 2-3 people and 2-4 hours.
Cable machine buying guide: how they work
A cable runs from a handle, over a set of pulleys, to the weight. When you pull the handle, the cable lifts the weight. When you let go, the weight lowers and draws the handle back.
Many machines use a weight stack. That's a column of flat plates with a pin through it. You move the pin to pick your load, so a weight change takes a second.
Other machines are plate-loaded, which means you add your own weight plates instead of using a stack. Body-Solid's Powerline PCCO90X crossover works this way. You slide plates onto a post, the same way you load a barbell.
The pulley ratio is how much of the stack you feel at the handle. A 4:1 ratio means 4 lb of stack for every 1 lb at the handle. Common ratios look like this:
- 1:1: you feel about what you pin. The handle and the stack move the same distance.
- 2:1: you feel about half, but the cable travels twice as far.
- 4:1: you feel about a quarter, with four times the cable travel.
Types of cable machines
Cable machines come in four main types. They differ in width, pulley count and how they load.
- Functional trainer. Two adjustable pulleys on one compact frame. For a small room, start with our functional trainers.
- Cable crossover. Two towers joined by a top bar, with open space in the middle. You stand between the towers and pull from either side. Browse our cable crossover machines if you have a wide wall.
- Single cable column. One tower with one adjustable pulley. You train one side at a time.
- Rack attachment. A pulley kit that attaches to a power rack you already own.
Multi-station gyms and Smith machine combos can include pulleys too. They're built around other stations, so we don't cover them here.
| Type | Floor space example (W x D) | Best for | Downside |
|---|---|---|---|
| Functional trainer | 61 x 55 in (PFT50) | Small rooms | No open middle like a crossover has |
| Cable crossover | 110 x 37 in (BFCCO10) | Wide walls, two-sided pulls | Takes the most wall width |
| Single column | 58 x 53 in (S2CC) | One-arm work | One pulley, one side at a time |
| Rack attachment | Your rack's footprint | Rack owners | Must fit your rack |
A functional trainer and a single column take similar floor space here, and a crossover is widest.
What to check before you buy
Four things decide whether a cable machine works for you: stack weight, pulley setup, space and build. Go through them in that order.
Stack weight: the mistake we see most
The most common mistake we see is a stack that's too small for the exercise a buyer cares about. One stack size doesn't suit every movement.
Lat pulldowns need much more weight than cable crossovers or tricep pushdowns. A stack that feels heavy on a pushdown can run out quickly on a pulldown.
The next section turns stack weight into handle weight.
On a plate-loaded model like the PCCO90X, your own plates set the load, so there's no stack to size. That's handy if you already own a set. Some stack models offer more than one stack size. The S2CC comes with a 160, 210 or 310 lb weight stack, so you can match it to your pulldowns.
Pulley ratio and height range
Take the PFT50 as a worked example. It has a 210 lb stack and a 4:1 ratio, according to Body-Solid's spec page. Divide 210 by 4 and you get about 52 lb at the handle. If your pulldowns need more than that, you'd want a bigger stack or a lower ratio.
Ratios vary by machine, and our data lists one only for the PFT50. We have no ratio for the BFCCO10 or the S2CC, and no stack size for the BFCCO10. We can't run the same math for them.
Height range is how high and low the pulley adjusts. A wide range lets you do high pulls like pulldowns and low pulls like rows on one machine. Our product data doesn't list a height range for any of the four machines in this guide.
Swivel pulleys help too. The PFT50's pulleys swivel 180°, which gives you more starting angles.
Floor space and ceiling height
Ceiling height is another common mistake. An 8-foot ceiling is 96 inches. The S2CC column stands 99 inches tall, so it won't fit under one.
The other machines in this guide stand 83 to 84 inches tall. Under an 8-foot ceiling, that leaves 12 to 13 inches of space above them.
Measure at the exact spot where the machine will stand. Beams, ducts, lights and garage door tracks can hang lower than the ceiling itself.
Floor space comes next. The PFT50 takes about 5 feet each way. Crossovers are the wide ones: the BFCCO10 is 110 inches wide, and the PCCO90X is 113 inches wide and 37 inches deep.
Then add room to use it. You stand in front of a functional trainer or between a crossover's towers. Keep space clear for a step or a lunge.
Build and warranty
One quick way to compare build on paper is the frame warranty. Our product data lists these:
- S2CC: lifetime on the frame and welds. 3 years on pulleys, bushings, bearings and hardware. 1 year on cables and upholstery.
- PFT50 and PCCO90X: 10 years on the frame and welds, and 1 year on parts like bushings, hardware, pads and grips.
- BFCCO10: 3 years on the frame and welds, 1 year on parts and 30 days on wear parts.
Look at the cable, too. The S2CC uses coated steel aircraft cable rated to 2,000 lb test. That "test" figure is the cable's rated strength from the listing, not a load to train with. Cables carry shorter coverage than frames: 1 year on both the S2CC and the PCCO90X. Check them often.
Models we sell, and who they suit
These four machines from our collection are matched to the room they fit, in no particular order. Prices are as of October 13, 2026.
| Model | Size, W x D x H (in) | Load | Frame warranty |
|---|---|---|---|
| PFT50 functional trainer | 61 x 55 x 84 | 210 lb stack | 10 years |
| PCCO90X crossover | 113 x 37 x 83 | Plates, not included | 10 years |
| BFCCO10 crossover | 110 x 37 x 83 | Load type not listed | 3 years |
| S2CC cable column | 58 x 53 x 99 | 160, 210 or 310 lb stack | Lifetime |
The PFT50 and S2CC list stack sizes, and frame warranties run from 3 years to lifetime.
For a small room or garage: Powerline PFT50
Got a spare room or garage with an 8-foot ceiling and about 5 x 5 feet of floor? Start with the PFT50, priced at $759. It has a 210 lb stack, pulleys that swivel 180° and a 10-year frame warranty.
Its no-cable-change design lets you move between exercises without re-routing the cable. A built-in chin-up bar and two nylon handles come with it.
Downside: at 4:1, you feel about a quarter of the stack at the handle. If heavy lat pulldowns are your main lift, you may outgrow it.
Body-Solid Powerline Functional Trainer PFT50
Functional trainer · 210 lb stack · 180° swivel pulleys · 55 × 61 × 84 in
A compact pick for a spare room or garage.
For a wide wall and plates you own: Powerline PCCO90X
A full crossover at $349.95, the PCCO90X has a 113 x 37 inch footprint and stands 83 inches tall. It carries a 10-year frame and welds warranty.
Being plate-loaded, it takes both Olympic and standard plates and includes two cable handles.
Downside: there's no stack. If you don't own plates and collars (the clips that hold plates on the post), you'll need to buy them. Changing weight also takes longer than moving a pin.
Body-Solid Powerline Cable Crossover PCCO90X
Cable crossover machine · 112 × 39 × 82 in footprint · 108 lb · 10-yr frame warranty
Best if you have a wide wall and a set of plates already.
Another full-width crossover: Best Fitness BFCCO10
Best Fitness designed this crossover for home and garage gyms with a wide wall. At $480, it's 110 inches wide and 83 inches tall, and our listing gives a 300 lb weight capacity.
How does it load? Neither the maker's product page nor its data sheet says whether it uses a weight stack or plates. With the load type not listed, ask us before you order if that matters to you.
On the plus side, it has 180-degree swivel pulleys, a no-cable-change design and nylon bushings that glide on chrome guide rods.
Downside: the warranty is the shortest here, at 3 years on the frame and welds.
Best Fitness Cable Crossover BFCCO10
Cable crossover with 300 lb capacity: 110 in wide, 83 in tall, steel frame
A full crossover for a home or garage gym with a wide open wall.
For a tall room: Pro ClubLine S2CC
The S2CC is a single cable column with a lifetime frame and welds warranty. Prices start at $3,010. Its 2 x 3 inch steel frame has a full cover over the weight stack.
Measuring 58 inches wide and 53 inches deep, it weighs 468 lb with the 160 lb stack and about 618 lb with the 310 lb stack.
Downside: at 99 inches tall, it needs a ceiling well above 8 feet. It also costs the most here.
Body-Solid Pro Clubline Series 2 Cable Column S2CC
Pro Clubline Series 2 cable column: 53 × 58 × 99 in, 468 lb, lifetime frame warranty
Made for a room with a high ceiling and a bigger budget.
What does a cable machine cost, plus delivery and assembly?
As of October 13, 2026, prices for the four machines in this guide run from $349.95 to $3,010. Lowest first:
- PCCO90X: $349.95. Plates and collars cost extra if you don't own them.
- BFCCO10: $480.
- PFT50: $759.
- S2CC: from $3,010 with the 160 lb stack, $3,115 with 210 lb and $3,335 with 310 lb.
That makes three rough tiers. The two crossovers sit under $500, the PFT50 sits in the middle at $759, and the S2CC stands alone above $3,000. For the extra money, the S2CC has the heaviest build in this guide. It has a 2 x 3 inch steel frame, a covered stack and a lifetime frame warranty.
Prices change, so confirm the figure on each product page before you order.
Delivery
Most of our cable machines ship by LTL freight unless your order says otherwise. LTL stands for less-than-truckload, which means your order shares a freight truck with other shipments.
The PCCO90X is the exception we know of. Its listing says it ships by parcel, within 1 business day, with 2-5 days in transit.
Before you order, ask us where the driver leaves the boxes and whether freight adds a cost. You can reach the team through our contact page.
These are heavy machines. The S2CC weighs 468 lb with the 160 lb stack and about 618 lb with the 310 lb stack. The PFT50 weighs 329 lb once built. Before delivery day, measure the doors, stairs and tight turns between the truck and your gym.
Assembly
Assembly takes 2-3 people and 2-4 hours. Lay out every part before you start, and follow the maker's manual step by step.
Once it's built, run each pulley through its full range with light weight. Watch that the cable stays seated in the pulley grooves.
Cable machine or free weights?
The main difference is direction. Free weights pull straight down, so your body position sets the angle. A cable pulls toward the pulley, so you change the angle by moving the pulley.
A stack machine also makes weight changes fast. You move a pin instead of loading plates or swapping dumbbells.
Skip a cable machine for now if your ceiling is too low, your room is tight or you mostly do barbell lifts. A rack and barbell come first in that case. Once you have a rack, a rack attachment can add cables later.
Torn between a compact trainer and a bigger cable machine? Our functional trainer vs cable machine guide compares them side by side.
Attachments to buy first
The PFT50 and PCCO90X each come with two handles. After that, these four cover most exercises:
- Rope. For tricep pushdowns and face pulls.
- Lat bar. A long bar for lat pulldowns. If pulldowns are your main lift, get this one first.
- Straight bar. For curls, pushdowns and rows.
- Ankle strap. For leg kickbacks and side leg raises.
You'll find all four in our cable handles and attachments. Check that the clip fits your machine's cable end before you order.
Frequently asked questions
How much stack weight do I need on a cable machine?
Enough for your heaviest pull, which is usually a lat pulldown. If you're unsure, pick a model that offers more than one stack size, like the S2CC.
Will a cable machine fit under an 8-foot ceiling?
Most of the ones in this guide will. The PFT50, PCCO90X and BFCCO10 stand 83 to 84 inches tall. The 99-inch S2CC won't.
How many people does it take to assemble a cable machine?
Two to three. Clear a path from the door to the room first, since most arrive by LTL freight.
Is a functional trainer the same as a cable machine?
It's one type of cable machine. A functional trainer puts two adjustable pulleys on one compact frame.
Can I use weight plates instead of a stack?
Yes, on a plate-loaded model like the PCCO90X. It takes both Olympic and standard plates, and the plates and collars aren't included.
Before you order a cable machine, measure this
This cable machine buying guide boils down to one order of checks: measure your ceiling, then your floor, then check that the stack covers your heaviest pull.
